1, Features of truck wheel alignment clamp and extension arm kit.
● Suitable for most of truck wheel alignment machines, like CCD, 3D wheel alignment machine, etc.
● Clamp range fits rims from 7 inch to 15 inch(178 mm to 381mm), extension arm can clamp tyre diameter 720-1200mm.
● The turning knobs quickly adjust the clamp range to fit various rim sizes.
● Durable Locking pin is easy to install and locks the target to the wheel clamp securely.
● High strength aluminum blocks and strong steel rods to keep the high strength for the whole clamp.
2, Specification of truck wheel alignment clamp
Application | All wheel alignment machine | Clamping size | 11-30 inch rim
|
Target hole diameter | Φ15,Φ16 or 18mm | Accumulative tolerance | ≤0.20mm |
Raw material | Alu, steel, plastic | Color | Grey, red,etc
|
N.W | 18KGS/CTN | G.W | 25KGS/CTN |
Package | 4PCS/CTN | One set incl. | 4pcs clamps+8PCS arms |
