High Precision customized wheel alignment turn plates
High Precision customized wheel alignment turn plates High Precision customized wheel alignment turn plates
High Precision customized wheel alignment turn plates High Precision customized wheel alignment turn plates
High Precision customized wheel alignment turn plates High Precision customized wheel alignment turn plates
High Precision customized wheel alignment turn plates High Precision customized wheel alignment turn plates
High Precision customized wheel alignment turn plates High Precision customized wheel alignment turn plates

loading

High Precision customized wheel alignment turn plates

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
Availability:
Quantity:

1, Specification for wheel alignment turntable.

Application

All wheel alignment machine and lift

Turntable size

L400*W400*H50MM

Top base plate diameter

345mm

Rotation degree

±50°

Raw material

Alu, steel, plastic

Color

Grey, red,etc

Load capacity

4-6 ton

Unilateral sliding distance

65mm

N.W

18KGS/CTN

G.W

20KGS/CTN

Package

2PCS/CTN

One set incl.

2pcs turntables+2pcs passing bridges+2pcs thrust blocks

Wheel alignment turn plates product specification:

● Turntables help to do wheel alignment test.

● Includes two lockingk pins to hold the plate in place, the locking pin to make the plates zeroed and in position.

● ± 45° rotating ability in left and right.

●  To be used for hydraulic lifts or pit racks fitted with recesses for turnplates both 40 and 50mm high.
